Cooling Options Air cooling, optional processor liquid cooling Fans • Standard fan/High performance SLVR fan/High performance GOLD fan • Up to six hot plug fans Dimensions • Height – 86.8 mm (3.41 inches) • Width – 482 mm (18.97 inches) • Depth – 758.3 mm (29.85 inches) - without bezel 772.14 mm (30.39 inches) - with bezel Form Factor 2U rack server Embedded Management • iDRAC9 • iDRAC Service Module • iDRAC Direct • Quick Sync 2 wireless module Bezel Optional LCD bezel or security bezel Open Manage Software • Open Manage Enterprise • Open Manage Power Manager plugin • OpenManage SupportAssist plugin • OpenManage Update Manager plugin Mobility OpenManage Mobile Integrations and Connections OpenManage Integrations • BMC Truesight • Microsoft System Center • Red Hat Ansible Modules • VMware vCenter and vRealize Operations Manager OpenManage Connections • IBM Tivoli Netcool/OMNIbus • IBM Tivoli Network Manager IP Edition • Micro Focus Operations Manager • Nagios Core • Nagios XI Security • Cryptographically signed firmware • Secure Boot • Secure Erase • Silicon Root of Trust • System Lockdown (requires iDRAC9 Enterprise or Datacenter) • TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ Embedded NIC 2 x 1 GbE LOM Network Options 1 x OCP 3.0 (x8 PCIe lanes) GPU Options Up to two double-width 300 W, or three single-width 150 W, or six single-width 75 W accelerators Ports Front Ports • 1 x Dedicated iDRAC Direct micro-USB • 1 x USB 2.0 • 1 x VGA Rear Ports • 1 x USB 2.0 • 1 x Serial (optional) • 1 x USB 3.0 • 2 x RJ-45 • 1 x VGA (optional for liquid cooling configuration) Internal Ports • 1 x USB 3.0 PCIe Up to 8 x PCIe Gen4 slots (up to 6 x16) with support for SNAP I/O modules Operating System and Hypervisors • Canonical Ubuntu Server LTS • Citrix Hypervisor • Microsoft Windows Server with Hyper-V • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi For specifications and interoperability details, see Dell.com/OSsupport. OEM-ready version available From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. For more information,
